BMW X5: Active seat ventilation
Principle
Integrated fans in the seat and armrest areas provide a comfortable seat temperature.
Overview
.png)
Active seat ventilation
Turning on
1. Press the button.
2. Select the ventilation level:
- Press the button once for each level.
- Turn the Controller until the desired level is reached. Press the Controller.
- Select the desired level on the touchscreen.
Highest level reached when three blue LEDs light up on the button or three blue bars are shown on the Control Display.
Turning off
Press and hold the button, until
the
LEDs turn off.
Seat climate control
Principle
The seat climate control combines the functions of the seat heating and active seat ventilation.
General information
The seat heating and active seat ventilation are operated with a common button on the climate control panel.
When both systems are active, a push of the button reduces the intensity of both functions by one level each.
The last active function or function that is configured with higher intensity will be activated directly when the system is switched on again.
When both functions with the same intensity configuration are deactivated, the system will automatically activate the seat heating.
Overview
Seat climate control
Turning on
1. Press the button.
2. Select the desired setting via the touchscreen.
One red and one blue LED each will illuminate.
Turning off
Press and hold the button, until
the
LEDs turn off.
